INTEL Server Chassis R1304WFXXX
Popis
Parametry
Hlídací pes
| Code Name | Buffalo Peak |
| Essentials | |
| Expected Discontinuance | 2H'2020 |
| Limited 3-year Warranty | Yes |
| Chassis Form Factor | 1U, Spread Core Rack |
| Chassis Dimensions | 16.93" x 27.95" x 1.72" |
| Target Market | Cloud/Datacenter |
| # of Power Supply Included | 0 |
| Redundant Fans | Yes |
| Redundant Power Supported | Supported, requires additional power supply |
| Backplanes | Included |
| Included Items | (1) 3.5” Hot-swap drive bays, includes (1) 12 Gb SAS backplaneFR1304S3HSBP, & (4) 3.5” hot swap drive tool less carriers FXX35HSCAR2,(1) Pre-installed Standard Control Panel assembly, (1) Server board to backplane 150mm I2C cable, (1) 850mm MiniSAS HD cable AXXCBL850HDHRT, (1) 350mm Backplane power cable, (2) Chassis handles (1 set) installed A2UHANDLKIT3, (1) Air duct, (6) Dual rotor system fans FR1UFAN10PW, (2) CPU heat sinks, 39 fin passive (2) CPU heat sink “No CPU” label inserts, (2) Standard CPU Carriers, (2) 1 slot PCIe x16 Riser Card, (8) DIMM slot blanks, (1) Chassis Stiffener Bar, (1) Power Supply Bay blank insert, (2) AC Power Cord retention strap assembly |
| Supplemental Information | |
| Description | 1U server chassis designed for the Intel® Server Board S2600WF family, supporting four 3.5 inch hot-swap drives. Power supply sold separately |
| Memory & Storage | |
| # of Front Drives Supported | 4 |
| Front Drive Form Factor | Hot-swap 3.5" HDD or 2.5" SSD |
| Package Specifications | |
| Max CPU Configuration | 2 |
.
Druh produktu:
Skříň
Aktuální cena produktu je16870Kč
s dph
